Shell and Tube Evaporator

This Shell and Tube Evaporator is a high-efficiency evaporation equipment for industrial concentration and solvent recovery. It features stable operation, anti-scaling performance and low energy consumption, reducing operating costs and ensuring continuous production for various industrial scenarios.
Send Inquiry
Description

Shell and Tube Evaporator Tube Heating Exchanger Shell Exchanger

Product Overview



Our shell-and-tube evaporators are designed for liquid concentration, solvent evaporation, and waste-liquid volume reduction. They effectively mitigate common issues found in conventional equipment, such as local overheating, tube-side fouling, seal leakage, and unstable output.

We offer fast-track single-unit delivery as well as full-scope EPC contracting services.

95001



96001

Product Description



Technically, our optimized design provides the following advantages:

  • Uniform heat absorption: Optimized tube layout and flow-channel design.
  • Zero hot spots: Balanced shell-side and tube-side flow protects heat-sensitive materials.
  • Reliable sealing: Integral tubesheet construction ensures high mechanical rigidity.
  • Long-term operation: Improved flow geometry suppresses fouling accumulation.



In terms of manufacturing and delivery, each unit is built in accordance with ASME codes, using traceable raw materials and precision automatic welding. Before shipment, each unit undergoes PMI material verification, full-process non-destructive testing (NDT), and hydrostatic/sealing tests. We can customize evaporation capacity, materials, dimensions, and surface treatment according to your process datasheet.



Basic Product Parameters



Item Specification

Structural Type

Shell‑and‑tube, fixed tube‑sheet design
Available Material Carbon steel, SS304 / SS316L, nickel‑base alloy; titanium optional for heavy corrosion service
Evaporation Capacity Custom‑tailored per process requirement; large‑capacity units for EPC projects
Design Temperature ‑20 ℃ ~ +350 ℃
Design Pressure Up to 5.0 MPa; higher rating upon custom design

Applicable Medium

Industrial wastewater, chemical solution, light‑to‑medium corrosive fluid, organic solvent
Customization Scope Evaporation capacity, tube specification, material grade, shell dimension, nozzle standard, anti‑corrosion coating and accessories



Core Advantages & Competitor Comparison



Comparison Item General-grade Market Shell-and-tube Evaporator Our Shell and Tube Evaporator

Evaporation Performance

Uneven heating, unstable output; local overheating risk

Optimized flow path, stable capacity; less hot-spot degradation

Fouling & Maintenance

Poor flow distribution, fouling buildup, frequent shutdown

Better flow geometry reduces deposits; longer cleaning interval

Sealing & Reliability

Standard tube-sheet welding; higher leakage risk in corrosive service

Heavy-duty integral tube-sheet, precision welding; more reliable sealing

Total Cost & Service

High energy use, downtime loss, limited engineering support

Stable output reduces OPEX; single-unit & EPC support available



shell and tube evaporator





97001

Why our solution performs better



  1. CFD-optimized internal flow channel: balance evaporation performance and reasonable pressure drop, eliminate local hot-spots.
  2. Strict quality gate: material traceability, full weld NDE, hydro-sealing test; complete test reports for project archive.
  3. Flexible business mode: fast-track single-unit delivery for pilot orders; dedicated project team for large long-duration industrial projects.
  4. Full after-sales system: remote technical support, installation guidance; on-site service negotiable for key bulk projects.



Packaging and Transportation

The equipment surface is treated with anti-corrosion and anti-rust coating, wrapped with moisture-proof and shockproof materials, and reinforced with a steel frame to prevent collision, corrosion and deformation during transportation. We cooperate with professional heavy-duty logistics to track the whole process and ensure the equipment arrives at the project site intact.

Applications

Suitable for liquid concentration, solvent recovery and waste liquid reduction under corrosive, fouling-prone conditions. We serve pilot workshops and full-plant EPC projects across petrochemicals, environmental treatment, pharma & fine chemicals, food and other heavy-duty evaporation fields requiring stable continuous running.

98001



modular-1
CTA

Troubled by low evaporation efficiency, high energy consumption and frequent scaling of evaporators? Contact us now to get a customized Shell and Tube Evaporator solution. We provide one-stop design and manufacturing to fit your process needs and reduce long-term operation costs.



FAQ



Q: What is the core advantage of this Shell and Tube Evaporator?

A: It combines stable shell-and-tube structure with high evaporation efficiency, energy-saving, anti-scaling and suitable for long-term continuous operation.

Q: Can it handle corrosive and viscous media?

A: Yes, we can customize special materials to adapt to corrosive media, and the optimized flow channel is suitable for slightly viscous materials.

Q: Will it cause material deterioration during evaporation?

A: No, the uniform heat exchange design avoids local overheating and effectively protects the material properties.

Q: Can evaporation capacity be customized according to needs?

A: Yes, we customize evaporation capacity, structure and materials according to your actual process parameters.

Q: How to ensure product quality and service life?

A: Strict factory testing and full-process quality control are carried out to ensure long service life and low failure rate.
